Molybdenum target

Purity specifications: 99.95%; 99.98%
Density: ≥10.10g/cm3
Organization: average grain size is less than 150 microns, typical target and surface structure

Specification range: (10-20) mm×(200-1450) mm×≤3000 mm

Specifications of the supplied products:

9.5mm×160mm×925mm

15mm×133mm×778mm 19mm×200mm×2700mm

10mm×885mm×960mm 14mm×1400mm×1700mm

16mm×1431mm×1650mm

Purity specifications: 99.95%; 99.98%

Density: ≥10.10g/cm3

Structure: average grain size is less than 150 microns, typical target and surface structure

As shown in the figure below: Average hardness range: HV180-200 Ultrasonic flaw detection: The maximum equivalent defect is not more than 0.5mm;





the microstructure of rectangular target

Wide molybdenum metallographic
